Genesis Advanced Technologies 5.2 loudspeaker Specifications

Sidebar 1: Specifications

Description: Four-way, floorstanding loudspeaker with powered woofer section. Drive-units: two 1" (25mm) circular aluminum-ribbon tweeters, 4.5" (115mm) titanium upper-midrange cone, two 6.5" (165mm) aluminum lower-midrange cones ("midbass couplers"), three 8" (200mm) aluminum woofer cones. Inputs: speaker level on 4mm terminals, line-level on balanced XLR, LFE line-level on XLR. Output: LFE pass-through on XLR. Frequency response: 20Hz–36kHz, ±3dB. Crossover frequencies: 71–135Hz, 300Hz, 3.6kHz. Nominal impedance: 4 ohms. Sensitivity: 90dB/2.83V/m. Maximum power handling: 500W. Woofer amplifier power: 500W, class-D, servo-controlled.
Dimensions: 44" (1118mm) H by 11" (280mm) W by 22" (560mm) D. Weight: 140 lbs (63kg).
Finishes: Rosewood, Piano Black, Arctic Ice, Bird's-Eye Maple.
Serial Numbers Of Units Reviewed: None found.
Price: $16,000/pair. Approximate number of dealers: 25. Warranty: 3 years, parts & labor.
Manufacturer: Genesis Advanced Technologies, 654 S. Lucile Street, Seattle, WA 98108. Tel: (206) 762-8383. Fax: (206) 762-8389. Web: www.genesisloudspeakers.com.
