Accuphase DP-100 Super Audio CD transport & DC-101 Digital Processor Specifications
Accuphase DP-100 Super Audio CD transport: Plays CD, CD-R, and SACD single-layer, dual-layer, and hybrid (SACD/CD) discs. Laser diode wavelength: SACD, 650nm; CD, 780nm. Digital outputs: RJ-45 HS-Link and RCA S/PDIF. Power consumption: 20W.
Dimensions: 18 11/16" (475mm) W by 6 5/16" (160mm) H by 15 11/16" (398mm) D. Weight: 42.3 lbs (19.2kg) net.
Serial number of unit reviewed: G0Y076.
Accuphase DC-101 Precision Digital Processor: Digital inputs: RJ-45 HS-Link, RCA S/PDIF, TosLink. Sampling frequencies: 32, 44.1, 48, 88.2, and 96kHz, 16-24-bit 2-channel PCM; 2.8224MHz, 1-bit 2-channel DSD. Digital outputs: RCA S/PDIF, TosLink. D/A converter: 12x 24-bit Multiple Delta Sigma. Frequency response: 0.5Hz-50kHz, +0/-3dB. Total harmonic distortion: 0.0008% (20Hz-20kHz). S/N Ratio: 116dB. Dynamic range: 112dB (24-bit input, low-pass filter off). Channel separation: 108dB (20Hz-20kHz). Output voltage and impedance: balanced, 2.5V at 50 ohms on XLRs, 2.5V at 50 ohms on RCAs. Output level control: -84dB to 0dB (digital). Power consumption: 24W.
Dimensions: 18 11/16" (475mm) W by 5 7/8" (150mm) H by 15 11/16" (398mm) D. Weight: 45.9 lbs (20.8kg) net.
Serial number of unit reviewed: G0Y072.
Both: Approximate number of dealers: 35.
Manufacturer: Accuphase Laboratory, 2-14-10, Shin-Ishikawa, Aoba-Ku, Yokohama 225-8508, Japan. US distributor: Axiss Distribution, 17800 South Main Street, Suite 109, Gardena, CA 90248. Tel: (310) 329-0187. Fax: (310) 329-0189. E-mail: firstname.lastname@example.org. Web: www.axiss-usa.com, www.accuphase.co.jp.
