Portal Audio Paladin monoblock power amplifier Specifications

Sidebar 1: Specifications

Description: Solid-state monoblock power amplifier. Maximum output power: 200W into 8 ohms (23dBW), 360W into 4 ohms (22.55dBW). Maximum output current: 20A. Voltage gain: 28dB. Frequency response: 5Hz–100kHz, ±3dB. Distortion: <0.1% THD, 20Hz–20kHz. Slew rate: >50V/µs. Damping factor: >250. Input impedance: 10k ohms or 50k ohms single-ended, 20k ohms or 100k ohms balanced.
Dimensions: 17" (435mm) W by 4.5" (115mm) H by 12" (310mm) D. Shipping weight: 40 lbs (18.2kg).
Serial Numbers Of Units Reviewed: M5 00494/495.
Price: $3500/pair. Approximate number of dealers: 1 (sold direct only). Warranty: 3 years parts & labor; 60-day "risk-free" audition.
Manufacturer: Portal Audio, 6626 Charter Hills Road, Charlotte, NC 28277. Tel: (888) 737-4434. Fax: (704) 543-0207. Web: www.portalaudio.com.

COMPANY INFO
Portal Audio
6626 Charter Hills Road
Charlotte, NC 28277
(888) 737-4434
