Plinius SA-Reference power amplifier Specifications

Sidebar 1: Specifications

Description: Solid-state two-channel power amplifier. Output power (both channels driven, 20Hz–20kHz): 300Wpc RMS into 8 ohms (24.8dBW), 450Wpc RMS into 4 ohms (23.5dBW); 1000Wpc RMS into 8 ohms (30dBW) in bridged and true balanced mono modes. Frequency response: 20Hz–20kHz, ±0.2dB, 0dB at 0Hz, –3dB at 70kHz. Distortion: typically <0.05% THD at rated power, 0.1% THD and IM worst case prior to clipping. Current output: 70A short-duration peak per channel (fuse-protected). Risetime: typically <4µs. Input impedance: 47k ohms. Gain: 32dB on RCA inputs, 38dB on balanced inputs. Hum & noise: 100dB below rated output, 20Hz–20kHz, A-weighted.
Dimensions: 20" (510mm) W by 10.75" (275mm) H by 21" (535mm) D. Weight: 125 lbs (57kg).
Serial Number Of Unit Reviewed: 2676.
Price: $14,495. Approximate number of dealers: 12.
Manufacturer: Plinius Audio Ltd., 23 Walkers Road, Longburn, Manawatu, P.O. Box 1836, Palmerston North, New Zealand. Tel: (64) 6-354-8583. Fax: (64) 6-354-8586. Web: www.pliniusaudio.com. US distributor: Elite Audio Video Distribution, 1027 N. Orange Drive, Los Angeles, CA 90038. Tel: (800) 457-2577, x22. Web: www.themusic.com.
