Flatline Design 175 loudspeaker Specifications

Sidebar 1: Specifications

Description: Three-way hybrid loudspeaker. Drive-units: 69" treble/midrange ribbon, 5" plastic-cone midrange/upper-bass driver, 10" pulp-cone, side-firing woofer. Crossover frequencies: 350Hz and 100Hz. Crossover slopes: first-order, 6dB/octave. Impedance: 3–5 ohms. Frequency response: 35Hz–40kHz ±3dB. Sensitivity: 88dB/W/m.
Dimensions: 71" H by 14" W by 12.5" D. Weight: 75 lbs each.
Serial numbers of units reviewed: 175-1014/1015.
Price: $4495/pair in cherrywood, $3995/pair in oak (1994); no longer available (2010). Approximate number of dealers: 7. Warranty: 3 years parts & labor.
Manufacturer: Flatline Design, Blountsville, AL 35031 (1994). Company no longer in existence (2010).
