Esoteric MG-20 loudspeaker Specifications

Sidebar 1: Specifications

Description: Two-way, reflex-loaded, floorstanding loudspeaker. Drive-units: 1" (25mm) magnesium-dome tweeter, two 6.5" (165mm) magnesium-cone woofers. Crossover frequency: 1.9kHz. Crossover slopes: second-order low-pass, third-order high-pass. Frequency response: 38Hz–48kHz, –6dB. Sensitivity: 89dB/2.83V/m. Nominal impedance: 6 ohms. Minimum impedance: 3.7 ohms. Power handling: 20–170W.
Dimensions: Speaker: 41.75" (1061mm) H by 8.5" (216mm) W by 10.7" (272mm) D. Internal volume: 21.5 liters. Weight: 33 lbs (15kg). STD-MG-20 stand: 10.2" (260mm) W by 1.4" (36mm) H by 12.2" (310mm) D. Weight: 9 lbs (3.9kg).
Finish: American cherry veneer.
Serial Numbers Of Units Reviewed: 800051600 70510 464841 (both), 0030125 & 6 (stands).
Price: $9000/pair. STD-MG20 stand: $1500/pair. Approximate number of dealers: 22.
Manufacturer: Esoteric, a division of TEAC America, Inc., 7733 Telegraph Road, Montebello, CA 90640. Tel: (323) 726-0303. Fax: (323) 727-7656. Web: www.teac.com.

COMPANY INFO
Esoteric, a division of TEAC America, Inc.
7733 Telegraph Road
Montebello, CA 90640
(323) 726-0303
