Coda Technologies S5 power amplifier Specifications

Sidebar 1: Specifications

Description: Solid-state, remote-controllable, stereo amplifier with class-A output stage. Output power: 50W RMS into 8 ohms (17dBW), 100W RMS into 4 ohms (17dBW). Gain: 26dB at 8 ohms. Maximum current: 100A peak per channel. Input impedance: 50k ohms (RCA), 1k ohm (XLR). Output impedance: 0.03 ohm, 20Hz–20kHz. Frequency response: DC–100kHz, –3dB. Distortion: <0.03%, 10Hz–20kHz at 125W, both channels driven, 2–8 ohms. Noise: –120dB ref. to rated output. Power requirement: 450W maximum at rated output.
Finishes: Black, silver, graphite-anodized aluminum.
Serial number of unit reviewed: SX40508A.
Dimensions: 19" (487mm) W by 6" (154mm) H by 12.5" (320mm) D. Weight: 45 lbs (20.5kg).
Price: $3950. Approximate number of dealers: 22. Warranty: 10 years, parts & labor.
Manufacturer: The Continuum Group, 8274 Mediterranean Avenue, Sacramento, CA 95826. Tel: (916) 383-3653. Fax: (916) 386-8296. Web: www.coda-continuum.com.
