Bel Canto Ref1000M monoblock power amplifier Specifications

Sidebar 1: Specifications

Description: Solid-state monoblock power amplifier with class-D output stage. Input: single-ended RCA or balanced XLR. Output: one set WBT 5-way safety binding posts. Power Output: >500W into 8 ohms (27.8dBW), >1000W into 4 ohms (27.8dBW). Minimum Load: 2 ohms. Voltage gain: 27dB (single ended or balanced input). Peak Output Current: 45A. Frequency Response: 20Hz–20kHz, ±0.5dB all loads. THD+N: 0.007% 1W, 1KHz, 4 ohms. IMD (CCIF): 0.0007%, 1W, 14:15KHz, 4 ohms. Output noise: 90µV RMS A-weighted, 10Hz–20kHz. Damping factor: >1000. Output Impedance at 100Hz: <8 milliohms. Input impedance: 100k ohms (RCA), 200k ohms (XLR). Input Voltage for Max Output: 3V RMS.
Dimensions: 8.5" (216mm) W by 3.5" (88mm) H by 12" (305mm) D. Weight: 18.5 lbs (9kg).
Serial number of review sample: RI-149.
Price: $5990/pair. Approximate number of dealers: 65.
Manufacturer: Bel Canto Design, 221 N. First Street, Minneapolis, MN 55401. Tel: (612) 317-4550. Fax: (612) 359-9358. Web: www.belcantodesign.com.

COMPANY INFO
Bel Canto Design
221 N. First Street
Minneapolis, MN 55401
(612) 317-4550
